How to Print with a Rotary Printing Device on UV Printer

How to Print with a Rotary Printing Device on UV PrinterThe uv printer has a wide range of applications, and there are many materials that can be printed. However, if people want to print on rotary bottles or mugs, at this time, they need to use rotary printing equipment to print. So this article will help them to learn how to install and use a rotary printing device print on uv printer.

Introduction: The uv printer has a wide range of applications, and there are many materials that can be printed. However, if they want to print on rotary bottles or mugs, at this time, they need to use rotary printing equipment to print. So this article will help people to learn how to install and use a rotary printing device print on uv printer.

The following are specific instructions:

Operations before install the rotary printing device

1. Power on the machine, switch to the machine mode;
2. Still open the software in platform mode, and then move the platform out;
3. Move the carriage to the highest position;
4. Quit the software and switch to rotary mode.

Steps to install rotary printing device

1. People can see there are 4 screw holes around the platform. Corresponding to the 4 screw holes of the rotary printing device;
2. There are 4 screws to adjust the height of the stand. The stand is lowered, people can print bigger cups;
3. Install the 4 screws and insert the signal cable.

Open the software and switch to rotary mode. Click feed or back to check if the installation is successful

Change the Y moving speed value to 10

Place the cylindrical material on the holder

1. People need to make a picture of step calibration (Set paper size 100*100mm)
2. Making a wireframe picture, set picture h length to 100mm and w width to 5mm (Picture Centered)
3. Selecting mode and send
4. Setting the actual height of the print head surface from the material to 2mm
5. Entering X coordinate of the printing start
6. Find the position on the platform scale
7. Printing cylindrical material (Don’t choose Y coordinate)

People can see that the printed horizontal border isn’t good because the step is wrong.

Operator need to use a tape measure to measure the actual printed length.

People set the height of the picture to 100mm, but the actual measured length is 85mm.

Move input value to 100. Run the length input value 85. Just click once to calculate. Click apply to save to parameters. they will find the pulse value changes. Putting the picture again to confirm. Please change the X coordinate of the staring position to prevent the printing of the pictures from overlapping

The set length of consistent with the actual printing length, people can print the pictures. If the size still has a little error, they need to continue to enter the value on the software and calibrate. After finished, they can print the cylindrical materials.
